Tango 363 Port MiMo dual band WiFi ceiling mounted Antenna

The Tango 36 is a ceiling-mounted embedded antenna designed for tri-band Wi-Fi applications. Featuring a 3-port MiMo configuration, each internal antenna is arranged on a different spatial plane to optimise signal diversity and minimise
multi-path fading.
It supports 2.4 GHz and 5 GHz ISM bands, including the full Wi-Fi 6E spectrum up to 7125 MHz, making it ideal for next-generation Wi-Fi installations. Its compact dome-shaped enclosure ensures discreet integration into ceiling panels.
The radome is designed to withstand indoor environmental variations, and the antenna is supplied with three low-loss cables and reverse polarity SMA male connectors as standard.
Custom cable lengths and connectors are available for volume requirements.

Key Features

• Supports Dual Band Wi-Fi 2.4G & 5G
• Supports Wi-Fi 6E for extended high-band coverage
• Supports IEEE 802.11ac and 802.11ax
• Triple antenna MiMo system for enhanced throughput
• Peak gain up to 4.35 dBi
• Ceiling-mounted for optimised indoor coverage
• Ground plane independent

Typical Applications

• Ceiling-mounted wireless access points
• In-building wireless coverage extension
• Enterprise Wi-Fi deployment
• Indoor wireless repeaters
• Embedded in indoor smart infrastructure

Electrical Specifications

• Frequency range: 2400-2500 MHZ / 5150-7125 MHz
• Impedance: 50 Ohm
• Max VSWR: 2.27
• Peak gain: Up to 4.35 dBi
• Max power: 10W
• Polarization: Vertical
• Ground plane independent: Yes

Environmental Specifications

• Operating Temperature:-30 – +60°C
• Storage Temperature:-30 – +60°C

Mechanical Specifications

• Dimensions: L90 Ø x H40.5mm
• Weight: 240 g
• Cable: 3x Low Loss 100 Cable (1.5m)
• Connector: 3x SMA Male Reverse Polarity
• Material Radome: ABS
• Mounting method: Through Hole / Ceiling Mount
